| AC Supply 415V, soHz, 3 Phase (Casting Body) | ||||||||||
| Out Put | Frame | Speed | Saft | Key | Bearing | Approx | ||||
| HP | K.W. | Size | Volt | RPM | Amps | Size | Size | Size | Weight Kg. | |
| 1 | 0.5 | 3.37 | 71 | 415 | 1410 | 0.95 | 16mm | 5mm | 6204/6203 | 9.5 |
| 2 | 1 | 0.75 | 80 | 415 | 1425 | 1.45 | 19mm | 6mm | 6204/6204 | 15 |
| 3 | 1.5 | 1.1 | 90 s | 415 | 1420 | 2.5 | 24mm | 8mm | 6205/6204 | 18 |
| 4 | 2 | 1.5 | 90L | 415 | 1445 | 3.1 | 24mm | 8mm | 6205/6205 | 23.5 |
| 5 | 3 | 2.2 | 100 | 415 | 1450 | 4.6 | 28mm | 8mm | 6206/6206 | 30 |
| 6 | 5 | 3.7 | 112 | 415 | 1435 | 7.5 | 28mm | 8mm | 6206/6206 | 41 |
| 7 | 7.5 | 5.5 | 132 | 415 | 1450 | 11.5 | 38mm | 10mm | 6208/6208 | 61 |
| 8 | 10 | 7.5 | 132 | 415 | 1455 | 15.5 | 38mm | 10mm | 6208/6208 | 73 |
